Pete’s Gear: Sunn Amplifiers

Sunn 100S Amplifiers

Click to view larger version. Southfield High School, Detroit, Michigan, 22 Nov. 1967, with two Sunn 100S amplifiers and 2×15 cabinets, playing a Gibson ES-335. (Photo: Bob Elliott)

Click to view larger version. 22 Nov. 1967, Southfield High School, Detroit, Michigan, with two Sunn 100S amplifiers and 2×15 cabinets, playing a Gibson ES-335. (Photo: Bob Elliott)

Beginning in August 1967 and for the early- to mid-1968 North American tours, Pete (and John) used Sunn amplifiers and cabinets, succeeding the use of U.S. Thomas Organ (Vox) Super Beatles, with Sunn 100S amplifiers and cabinets. The first known use of Sunn amps is 23 Aug. 1967 in Flint, Michigan. It’s possible these Sunn 100S amps were purchased on 15 or 16 Aug. 1967, during a two-day break in Nashville.

The Who were first exposed to Sunn amps through the Blues Magoos’ roadie on the July-September 1967 Herman’s Hermits tour, their first of North America.

The Who purchased additional Sunn gear, along with Sunn PA gear, from Manny’s in New York, likely on or around the 25 Nov., 1967, Village Theatre dates in New York. Bobby Pridden had indicated that it was bought a couple days prior to the 29 Nov., 1967, date in Scotch Plains, New Jersey, though footage from the 25 Nov., 1967, Village Theatre gig shows Sunn PA in use. (Pete also purchased Coral Hornet guitars at this time.)

As a part of their use, the Who also provided endorsement for the Sunn gear.

From 8 to 14 July 1968, Pete tried Sunn’s new Orion solid state offering.

The Sunn gear was abandoned at Canadian customs in Toronto on 15 July 1968, at which point Pete began using the Sound City gear previously used only in the UK/Europe.

Sunn logo

North America only

The reason for the difference in gear in the 1967 U.S./Canadian shows was that the group could not afford the cost of importing their full gear (Marshall in 1967, and Sound City in 1968) and, instead, hired or borrowed gear once arriving in the U.S. Because of their financial straits, Chris Stamp, the Who’s manager, signed the group to an exclusive agreement with Vox to use their gear in the States. On the first 1967 U.S. tours, including the March/April 1967 “Murray the K – Music in the Fifth Dimension” shows in New York, and the Monterey Pop festival in June, the Who used rented U.S. Thomas Organ (VOX) V1143 ‘Super Beatle’ 120w solid state amplifiers and 4×12 (w/two horns) cabinets. The inferior quality of the gear is evident in the Monterey Pop show, where Jimi Hendrix, who had “learned” his gear setup from Pete and the Who, was able to bring his Marshall 4×12s and 100-watt amps, to great effect.

On the first North American tour, with Herman’s Hermits and the Blues Magoos, which began 13 July 1967, the Who used Super Beatles. However, on the second day of the tour, 14 July 1967, in Portland, Oregon, the Blues Magoos purchased (and became sponsored by) Sunn amplifiers and a Sunn Coliseum PA.

Mark “Hoss” Amans, roadie for the Blues Magoos, has written that he purchased Sunn amplifiers and Coliseum PA in Tualatin, Oregon, on 14 July 1967, and secured sponsorship by Sunn for the Blues Magoos. Because the Herman’s Hermits were sponsored by Fender and had matching amps, and the Who were sponsored by Vox and had matching Super Beatles, he thought it appropriate that the Blues Magoos also have a matching backline. So as the tour rolled on, it is possible the Who used some of these Sunn amps as they transitioned away from the Super Beatles. The Who and Hermits did use the Sunn Coliseum PA for the tour.

Excerpted from Mark “Hoss” Amans book, Where The Action Was:

When we were in Calgary, the Blues Magoos didn’t have matching equipment on stage. Hermans Hermits were sponsored by Fender, and they had all large Fender-dual showman amplifiers. The Who were sponsored by Vox, and had six Super Beatle Vox amplifiers. This was an amplifier I was well familiar with, because when I was with the Raiders, we were sponsored by Vox, as well. I knew Con and Norm Sundholm, because Norm used to play bass with the Kingsmen, and his brother Con started an amplifier company called Sunn, out of Tualatin, OR, just south of Portland.

So when we got to Portland, OR, to play the second gig of the tour, I called up Norm at the plant and told him my situation with the Blues Magoos. Here we were in the beginning of our tour, and I needed amplifiers and PA, bad. The Who, and The Herman Hermits didn’t even carry a PA with them, and in those days, we always carried our own equipment. We very rarely relied on the house to supply amps or PA systems. Keep in mind that this was long before the huge rental systems came into play.

So I took Mike Esposito with me and went to the Sunn factory. We went inside and told them exactly what we needed, and the guys really came through for us and sponsored The Blues Magoos with all Sunn equipment. We had all of the amplifiers for all of the instruments that we needed, and I told them that I wanted a Sunn Coliseum PA system which was customized with two horns on top of each speaker cabinet and two bottoms to a side. So that’s four horns to a side, and two bottoms to a side. And to this day, I still love that system.

I got back to The Coliseum with all of the gear in plenty of time to start the show. Even though though The Blues Magoos were better known at the time than The Who, the guys volunteered to open the show, and they let The Who play second, and The Hermits headlined. So I set up all of the Sunn amplifiers and PA, brand new, right out of the cardboard box. Looked very impressive.

The tour manager, Ed McAdams, used to handle a lot of the Dick Clark tours, and he knew me well. He put me in charge of all three of the road crews, because of my past experience. So unloading the truck, we had all of the Super Beatle amps, all of the Fenders, and all of the new Sunn gear from Portland. Also, all three groups used the Sunn Coliseum PA system, and they all liked it a lot. So I had to teach other roadies and cross-train them on all of the gear on stage. I was also in charge of the stage set up, all of the lighting, the sounds, and backstage security.

In the middle of the tour, The Who had to break away on a couple of off days and go to Tennessee to record a song called “I Can See For Miles”. They had damaged their amplifiers so bad because on their ending song called “My Generation”, they would kick the drum kits over, jam the guitars into the speaker cabinets of the Vox Super Beatle amps, knock the amps over, and break the guitars and throw them into the audience.

They also played so loud that one night I was I was watching standing off on stage left next to Peter Townsend [sic], and I looked down behind him between him and the amps and I saw a brass screw coming out of the deck. The vibrations from the amps were so strong that it loosened the screw and came all the way out of the stage and fell over.

They asked us if they could use our Sunn amps to record the song, “I Can See For Miles”, and The Blues Magoos said, “Sure, go ahead.” So I can say my Sunn amps are the amps that are on that song.

When the tour was over, they left all of their broken gear with the Blues Magoos, and we put it in the garage of our band house. They didn’t want to take it back to England with them. During the tour I had called Warren T. Hampton at Vox, who was the artist relations manager, and told him these guys were destroying their equipment. He didn’t know exactly what to say and I described to him how they were jamming their guitar necks into the grill cloths and speakers and kicking over the amps.

In August 1967, Pete and John began using two Sunn 100S 60-watt amplifiers (featuring KT88 valves) powering two or four JBL-loaded 2×15 cabinets. The first documented use of Sunn amps by Pete is 23 Aug. 1967, where they were used along with the Super Beatles.

It’s possible these Sunn 100S amps were purchased on 15 or 16 Aug. 1967, during a two-day break in Nashville.

Bobby Pridden has indicated the group purchased additional Sunn gear, including a Sunn PA, from Manny’s in New York, around the 25 Nov., 1967, Village Theatre date in New York, and prior to the 29 Nov., 1967, date in Scotch Plains, New Jersey.

For the first 1968 North American tour, from February to April 1968, Pete used his Sound City gear for the first time in U.S. and Cananda, and possibly Sunn as well. However, for the second 1968 North American tour, beginning with the Shrine Auditorium in Los Angeles on 28 June, Pete returned to Sunn, using Sunn 100S amps for the Los Angeles dates, then Sunn Orion amps until 14 July 1968, at which point the group abandoned their Sunn gear at Canadian customs in Toronto after Pete and Roger had their passports stolen the night before in Cleveland, and were unable (or unwilling) to satisfy a $20,000 customs bond.

Following Sunn, they began using their Sound City gear in North America, with first known date at The Dome, Virginia Beach, Virginia, 20 July 1968.

Sunn 100S amplifier features:

  • 60 watts
  • Controls (left to right): two inputs, Volume, Treble, Bass and Contour controls, rocker switches for Power, Standby and Polarity
  • Two KT88 power valves
  • Dynaco transformer
  • GZ34 rectifier
  • 7025 preamp and 6AN8 phase inverter

Speaker cabinets:

  • Most all photographic evidence indicates both Pete and John used the Sunn 200S 2×15 rear-loaded folded-horn enclosures, which would have two JBL D140 15 speakers. Pete also appears to have occasionally used the Sunn 100S cabinet, which was the same size but featured one JBL D130 15 speaker and one JBL LE100S midrange driver with high-frequency acoustic lens/horn. Both the 100s and 200s cabinets were 42 high × 24 wide × 15 deep.

Pete used his setup in two basic configurations:

  • Traditional piggy-back, with two amplifiers, each sitting on (and powering) one 2×15 speaker cabinet.
  • Two amplifiers on a chair, powering two side-by-side 2×15 cabinets or two stacks of two 2×15 cabinets, similar to his “definitive” configuration of two amps and two stacks of two 4×12s.

Photo Gallery

Flint, Michigan, 23 August 1967, with Gibson SG EDS-1275 double-neck and Sunn 100S amps.

Atwood Stadium, Flint, Michigan, 23 Aug. 1967, with Gibson SG EDS-1275 double-neck and first known use of Sunn 100S amps. Two amp stacks at left are one Sunn 100S amp with two 2×15s, and stack at right is one Super Beatle.

Flint, Michigan, 23 August 1967, with Gibson SG EDS-1275 double-neck and Sunn 100S amps.

23 Aug. 1967, Atwood Stadium, Flint, Michigan, with Gibson SG EDS-1275 double-neck and first known use of Sunn 100S amps. Two amp stacks at left are one Sunn 100S amp with two 2×15s, and stack at right is one Super Beatle.

Flint, Michigan, 23 August 1967, with late use of Super Beatle, now paired with Sunn 100S.

23 Aug. 1967, Atwood Stadium, Flint, Michigan, with late use of a Super Beatle amp, and earliest known use of the Sunn 100S with two 2×15s.

23 Aug. 1967, Atwood Stadium, Flint, Michigan, with rear view of Sunn 100S with 2×15 cabinet.

23 Aug. 1967, Atwood Stadium, Flint, Michigan, with rear view of Sunn 100S with 2×15 cabinet. Courtesy whocollection.com.

Ca. 1967, two Sunn 100S amplifiers and 2×15 cabinets. Guitar is Gibson SG EDS-1275 6/12 double-neck.

23 Aug. 1967, Atwood Stadium, Flint, Michigan, with Gibson SG EDS-1275 6/12 double-neck, and first known use of one Sunn 100S amplifier and two 200S 2×15 cabinets.

19 Nov. 1967, from Sunn endorsement ad, with two Sunn 100S amplifiers and 2×15 cabinets. Guitar is 1959/1960 Gibson Les Paul SG TV model. Courtesy Mark Herman.

19 Nov. 1967, Hollywood Bowl, Los Angeles, from Sunn endorsement ad, with two Sunn 100S amplifiers and two cabinets, with the left one appearing to be a 100S cabinet with one JBL D130 15 speaker and one JBL LE100S midrange driver with high-frequency acoustic lens/horn. Guitar is 1959/1960 Gibson Les Paul SG TV model. Courtesy Mark Herman.

Click to view larger version. Southfield High School, Detroit, Michigan, 22 Nov. 1967, with two Sunn 100S amplifiers and 2×15 cabinets, playing a Gibson ES-335. (Photo: SoundCityChris)

Click to view larger version. 22 Nov. 1967, Southfield High School, Detroit, Michigan, with two Sunn 100S amplifiers and 2×15 cabinets, playing a Gibson ES-335. (Photo: SoundCityChris)

25 November 1967, at the Village Theatre (later the Fillmore East), New York, with two Sunn 100S amplifiers and 2×15 cabinets, smashing a Gibson 335.

25 Nov. 1967, at the Village Theatre (later the Fillmore East), New York, with two Sunn 100S amplifiers and 2×15 cabinets, smashing a Gibson ES-335.

Ca. 1968, two Sunn 100S amplifiers visible at far right. John’s Sunn 2×15 cabinet stacks visible in background. Effects pedal is unknown.

Ca. 1968, two Sunn 100S amplifiers visible at far right. John’s Sunn 2×15 cabinet stacks visible in background. Effects pedal is unknown.

28 June 1968, two Sunn 100S amplifiers and four 2×15 cabinets. Guitar is Fender Stratocaster.

28 June 1968, Los Angeles Shrine Auditorium, with two Sunn 100S amplifiers and four 2×15 cabinets, stacked vertically. Guitar is Fender Stratocaster.

29 June 1968, Los Angeles, two Sunn 100S amplifiers and four 2×15 cabinets, stacked horizontally. Guitar is Fender Stratocaster.

29 June 1968, Los Angeles Shrine Auditorium, two Sunn 100S amplifiers and four 2×15 cabinets, stacked horizontally. Guitar is Fender Stratocaster.

November 1967

Click to view larger versions. Photos of Sunn amp use on 29 Nov., 1967, at Union Catholic High School, Scotch Plains, N.J., following gear purchase at Manny’s in November 1967, Photos courtesy Angelo Del Monte. (Also the first use of the Coral Hornet.)

Click to view larger version. First use of Sunn amps, Union Catholic High School, Scotch Plains, N.J. –1. Photo courtesy Angelo Del Monte.

Photo courtesy Angelo Del Monte.

Click to view larger version. First use of Sunn amps, Union Catholic High School, Scotch Plains, N.J. –2. Photo courtesy Angelo Del Monte.

Photo courtesy Angelo Del Monte.

Click to view larger version. First use of Sunn amps, Union Catholic High School, Scotch Plains, N.J. –4. Photo courtesy Angelo Del Monte.

Photo courtesy Angelo Del Monte.

Click to view larger version. First use of Sunn amps, Union Catholic High School, Scotch Plains, N.J. –3. Photo courtesy Angelo Del Monte.

Photo courtesy Angelo Del Monte.

Collage of 29 Nov., 1967, at Union Catholic High School in Scotch Plains, New Jersey. View large version at The Who Concert Guide. (h/t Dave Goessling.)

Click to view larger versions. 29 Nov., 1967, at Union Catholic High School in Scotch Plains, New Jersey. Courtesy The Who Concert Guide. (h/t Dave Goessling.)

Collage of 29 Nov., 1967, at Union Catholic High School in Scotch Plains, New Jersey. View large version at The Who Concert Guide. (h/t Dave Goessling.)

Click to view larger version. Collage of 29 Nov., 1967, at Union Catholic High School in Scotch Plains, New Jersey. (h/t Dave Goessling.)

Amp detail

Generic 1967 Sunn 100s amplifier

Generic 1967 Sunn 100S amplifier. Courtesy sunn.ampage.org/site/museum/.
Controls, from left to right, Volume, Treble, Bass, Contour, Standby, Polarity, Power.

Sunn Orion solid state amps – July 1968

Click to view larger version. 13 July 1968.

Click to view larger version. 13 July 1968, Grande Ballroom.

For at least the July 8–14 dates of the second 1968 North American tour, Pete used a Sunn Orion solid state preamp and two 2×15 cabs.

From the Unofficial Sunn Museum Boards:

The Sunn Orion “series” was Sunn’s first solid state amp; the “head” was actually only a preamp. The power amp was a new solid state design and was built into the bottom of the speaker cabinet. They built an amp for guitars and for bass, and the grill cloth had vertical stripes on it that got wider as you moved left to right. The cabinets themselves were wider and taller than the typical Sunn “C” cabinet.

While prototyping these amps, Sunn shipped 16 of them to the UK to The Who, so that they could “field test” them. The Who used them exclusively on their album “Magic Bus”.

Only a few of them ever made it onto the market... the preamp section worked fine, but the early TO-3 transistors in the power amp were very fragile... if you bumped the amp/speaker cabinet around (as in doing a loadout) while the amps were still warm, the transistors would break.

Sunn shipped 40 or 50 amp modules to The Who during the recording of the Magic Bus album because they were so rough on the amps. After the album was completed, they shipped all the amps back to Sunn (in Tulalatin Oregon at the time). About four weeks later, a carton of “Magic Bus” albums arrived at Sunn so all the employees (including their high school summer draftsman, me) could have a copy as a “thank you” gesture. Sunn threw away (!) all of the returned Orion amps... put them in their dumpster.

(Note: It’s unlikely these amps were ever used in the studio, notwithstanding that “Magic Bus” was a compilation of previously recorded material released by Decca.)

12 July 1968

12 July 1968, Indiana Beach Ballroom

The last date the Orions were used was 14 July 1968, at Musicarnival, Cleveland, Ohio. Anyway Anyhow Anywhere:

The Who were dissatisfied with the Sunn sound system provided and started smashing gear early in the set at this 2,500-seat theatre-in-the-round tent, sparking a minor riot. The group continued on borrowed equipment from support act Cyrus Erie.

Rory Callaghan:

He smashed a sunburst Stratocaster. I cannot remember if it was a maple or a rosewood neck. He then proceeded to smash an amp or two. I believe that tour was sponsored by SUNN amplifiers. I think the guitar was smashed in frustration with the amplifiers. After a break, they returned to finish the show borrowing the local band’s amps (Cyrus Erie, whose members later formed the Raspberries).

During the Cleveland Musicarnival show on 14 July, 1967, Pete’s and Roger’s passports (and clothes) were stolen from the dressing room. The following day, on 15 July, The Who headed to Kingston, Ontario, Canada. Per the Concert File, en route in Toronto, customs officials demanded a $20,000 bond to release the band’s equipment. James McCormick, the promoter, chartered two aircraft to fetch The Who and entourage from Toronto after the customs had been satisfied. However, the Sunn equipment stayed behind. In Kingston, the promoter supplied instruments and equipment from a local source (including a soon-to-be-smashed 1958 Fender Stratocaster now owned by Mike Moore).

It has been assumed the abandoned Sunn gear was the Sunn 100S, etc., not the Orions, since the 100S was no longer seen in Pete’s setup. However, given that the Orions were used up to 14 July, it is possible it was some of the “16” Orion units, along with the original Sunn 100S amps that were left in Toronto.

After two more Canadian dates, the Who returned to the USA, Providence, Rhode Island, on 18 July, and had their Sound City gear shipped over from the UK, with the first known North American date at The Dome, Virginia Beach, Virginia, 20 July 1968.

Click to view larger version. 8 July 1968

Click to view larger version. 8 July 1968, Sacramento, California.

13 July 1968, Grande Ballroom.

Click to view larger version. 13 July 1968, Grande Ballroom.

13 July 1968, Grande Ballroom, with Sunn Orion detail. (Photo: SoundCityChris)

Click to view larger version. 13 July 1968, Grande Ballroom, with Sunn Orion detail. (Note: The Who played two shows this night, hence the slight differences in this photo.)

14 July 1968, Musicarnival, Ohio, with Sunn Orion detail.

Click to view larger version. 14 July 1968, Musicarnival, Warrensville Heights, Cleveland, Ohio, with Sunn Orion detail. Guitar effects pedal is Dallas-Aribiter Fuzz Face.

14 July 1968, Musicarnival, Ohio, with Sunn Orion detail. John’s Sunn 100S (top) and 200s (bottom) visible behind Keith.

Click to view larger version. 14 July 1968, Musicarnival, Warrensville Heights, Cleveland, Ohio, with Sunn Orion detail. John’s Sunn 100S (top) and 200s (bottom) visible behind Keith.

Borrowed Sunn cabinets – 1971

Sunn Who ad

Click to view larger version Sunn ad, ca. 1972, in Guitar Player magazine.

For a show at the Seattle Center Coliseum in Seattle, Wash., on 15 December 1971, Pete used borrowed equipment from the supporting act, as one of the Who’s equipment trucks had crashed en route from San Francisco. Keith also appears to be using a borrowed drumkit.

In the photos below, Pete appears to be using two Marshall JTM100 amps, three Sunn 4×12 cabinets and one Marshall 4×12 cabinet.

Sunn used the opportunity to produce a Sunn endorsement (see photo at right).

The Who at the Seattle Center Coliseum, 15 Dec., 1971

Photos copyright and courtesy of Jeff Gledhill. Please respect the owner of these photos and do not reuse them for public or private use.

Seattle Center show, photo courtesy of Jeff Gledhill.
Seattle Center show, photo courtesy of Jeff Gledhill.
Seattle Center show, photo courtesy of Jeff Gledhill.
Seattle Center show, photo courtesy of Jeff Gledhill.
Seattle Center show, photo courtesy of Jeff Gledhill.
